Mat Power Grapple

product--img
Bateman Mat Power Grapple Image
Bateman Mat Power Grapple Image

BPG-MT Models

The BATEMAN Mat Grapple is the ultimate attachment for positioning rig mats over wet terrain or environmentally sensitive areas, allowing for the use of heavy equipment.

  • Long-lasting AR450 steel body.
  • 360 degrees of continuous rotation.
  • Versatile utility tines.

PRODUCT SPECIFICATIONS

Product Specification

The BATEMAN Mat Grapple is the ultimate attachment for positioning rig mats over wet terrain or environmentally sensitive areas, allowing for the use of heavy equipment.

TECHNICAL SPECIFICATIONS

Model BPG160-484MT-072
Machine Class 13t - 27t
Max Opening in (mm) 72 (1,829)
Width in (mm) 48 (1,219)
Tines 5
Cylinder Size in (mm) 3 (76)
Cylinder Max. Pressure PSI (bar) 5,000 (345)
Weight lb (kg) 1,850 (839)
Model BPG160-484MT-102
Machine Class 9t - 50t
Max Opening in (mm) 102 (2,591)
Width in (mm) 48 (1,219)
Tines 5
Cylinder Size in (mm) 3 (76)
Cylinder Max. Pressure PSI (bar) 5,000 (345)
Weight lb (kg) 2,350 (1,066)
Model BPG200-545MT-102
Machine Class 13t - 50t
Max Opening in (mm) 102 (2,591)
Width in (mm) 54 (1,372)
Tines 5
Cylinder Size in (mm) 3 (76)
Cylinder Max. Pressure PSI (bar) 5,000 (345)
Weight lb (kg) 4,050 (1,837)
Model BPG300-726MT109
Machine Class 25t - 150t
Max Opening in (mm) 109 (27,69)
Width in (mm) 72 (1,829)
Tines 6
Cylinder Size in (mm) 4 (102)
Cylinder Max. Pressure PSI (bar) 5,000 (345)
Weight lb (kg) 5,600 (2,540)

Excavators and material handlers.

Can be fitted with our dangling rotator (DR) or  manipulated series rotator (MR). Can also be fitted with one-two side blades and/or and side teeth.
